精巧型高速分選閥 Compact High-Speed Sorting Valves

美名格股份有限公司

Staccato Technologies AB為要求極高的氣動控制提供專業解決方案。

我們致力於為客戶的特殊應用開發並生產完全整合的系統方案。Staccato 具高效能並取得專利的產品技術，一直是我們各式閥件與系統的核心，能在嚴苛的車用、自動化工業環境中提供穩定且精準的控制。

2018年，我們推出了獨特的定位控制單元。這項創新技術結合了Staccato閥門的高速與大流量特性、客製化電子控制，以及公司自研軟體，使精準氣動控制得以實現。

Staccato Technologies AB provides solutions for highly demanding pneumatic control.

We develop and produce totally integrated solutions for customer unique applications. The unique high performing and patented Staccato Valve technology is always the base for our valves and systems control in tough automotive and industrial environments.

In 2018, we saw the release of our unique Positioning Unit - an innovative technology made possible by the speed and flow of the Staccato valve, custom Electronics and in-house developed software.

方案內容

精巧型高速分選閥 Compact High-Speed Sorting Valves

此系列閥件專為高速分選設備設計，適用於以氣流脈衝（air burst）方式快速剔除並分選小型物件的機台。Staccato的6mm超窄型分選閥性能超越一般10 mm規格產品，使穀物分選、資源回收、礦物選別等設備得以提升分選解析度與整體效率。

切換時間：0.5 ms
閥口徑：1.5 mm
最大頻率：1000 Hz
壽命：20億次循環
電壓：12 VDC、24 VDC、48 VDC

Specifically developed for sorting machines that use air bursts to eject and sort small items in high-speed machines. Staccatos 6mm wide sorting valves outperform 10mm equivalents, enabling increased resolution on sorting machines for grain, recycling, mineral enrichment.

Switching time: 0.5mS.
Orifice: 1.5 mm
Max Freqency: 1000hZ.
Life time: 2 Billion Cycles
Voltages; 12VDC, 24VDC, 48VDC
